5U industrial server for high-performance computing

AKHET® HPC Server Endurance R5U450a

The R5U450a is the high-performance version of the Endurance series.

It combines the computing power of AMD Ryzen™ Threadripper™ PRO CPUs with support for up to two RTX 4080 Super GPUs and 4 TB DDR5 RAM.

This makes the server an extremely powerful platform for GPU compute, AI training, rendering and high-resolution visualizations.

With up to 128 PCIe 5.0 lanes, massive ECC DDR5 memory and a 10 GbE network, it is designed to meet the highest requirements in data centers or industrial edge applications.

We have optimized the system for maximum performance per node.

learn more

Request now Start configuration

Powerful industrial PC

AI/ML training and inference:
Training of complex AI models (e.g. image and speech recognition)
Real-time inference of large models in the edge or data center.
Rendering & simulation:
GPU-based rendering of realistic scenarios in architecture, automotive or film production.
Physical simulations or digital twins.
Video streaming & encoding in real time:
Processing multiple 8K streams simultaneously.
Live streaming platforms or video surveillance systems.
High-end digital signage & control rooms:
Control of signage arrays with 8K content.
Central processing unit for visualization in control rooms.
Scientific computing (HPC):
Computing-heavy applications in biotechnology, energy or research.

Processor: TDP 350W e.g. AMD Ryzen™ Threadripper™ PRO
Graphics cards: up to 2 RTX4080 Super (optional)
Memory: max. 4 TB DDR5 ECC registered memory
Boot drive: M.2 NVMe SSD
LAN: 2 x 10Gbe Intel® X710-AT2
Expansion slots: 6 x PCIe 5.0 x16, 1 x PCIe 5.0 x16 (x8 mode)
Power supply: 115-240 V AC
Power consumption: 9 A
Mounting: Rack server with rail
Connections: Rear I/O

Front I/O
2 x USB 3.1 Type-A
Power button

Rear I/O
2 x USB4® Type-C 40 Gbps
6 x USB Type-A 10 Gbps
1 x USB 2.0 Type-A
VGA
Audio
2 x Mini-DisplayPort-IN
BIOS Flashback
AC-IN (C19 plug)

Dimensions: (WxDxH) 430 x 448 x 220 mm
Material: Coated sheet steel
Weight: Approx. 21 kg
Mounting: Rack with rails

Temperature:
Storage: -20°C to +60°C
in operation: 0°C to 40°C
Humidity:
in storage: 10% to 95% *
in operation: 10% to 80%

* non-condensing

Data sheet

AKHET® Platform For OEM solutions

AKHET® Endurance series is based on our modular VarioFlex platform. We use it to develop not only our standard portfolio of industrial servers, but also OEM solutions for customers with very specific hardware requirements.

You haven't found an Endurance system that fits your use case perfectly?

Then familiarize yourself with the VarioFlex platform here. On this page, we show you what we can do for you as an OEM and how we can develop your dream server from the platform: tailored to your specifications, cost-efficient and with a fast time-to-market.

More about VarioFlex platform Our OEM/ODM services
